Fuel Saving 5kw 8kw 10kw Silent Diesel Generator Set Air Cooled Customizable
|
Fuel Saving 5kw 8kw 10kw Silent Diesel Generator Set Air Cooled Customizable
| Place of Origin | China |
| Brand Name | JIWEI |
| Certification | ce |
| Model Number | JW-YMT |
Product Details
Rated Voltage:
110V/220V/230V/380V/400V/440V,120 To 440V
Frequency:
50/60HZ
Speed:
3600rpm,3000/3600RPM,1500/1800
Rated Current:
5A-30A
Rated Power:
5kw-10kw
Output Type:
AC Single Phase,DC,AC 3 Phase,Other
Color:
Customizable
Engine Type:
Two-Cylinder Four-Stroke，Air-cooled Diesel Engine,ECU
Starting System:
Manual Start, Remote Start, Electric Start
Function:
Provide Electric Power
Fuel Tank Capacity:
10-25L，According To Customers' Requirement
Alternator Type:
Brush Alternator With AVR Or Brushless With AVR,Three Phase Alternator
Product:
5kw 8kw 10kw Silent Diesel Generator
Highlight:
10kw Silent Diesel Generator Set
,8kw Silent Diesel Generator Set
,Fuel Saving 5kw Diesel Generator
Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Payment Terms
T/T
Product Description
Fuel Saving 5kw 8kw 10kw Silent Diesel Generator Set Air Cooled Customizable
Overview
Silent diesel generators are specifically designed to minimize noise output, making them ideal for environments that require quiet operation. These generators combine fuel efficiency with reliable performance for various applications.
Key Features
- Low Noise Design: Uses soundproof materials and specially designed silencers to significantly reduce operational noise.
- High Efficiency: Provides stable power output with excellent fuel economy for extended operation periods.
- Durability: Robust diesel engine construction suitable for long-running and heavy-load conditions.
- Portability: Many models feature mobile designs for easy relocation and versatile use.
- Environmental Protection: Complies with modern emission standards for eco-friendly operation.
Applications
- Backup Power Supply: Emergency power for hospitals, data centers, and critical facilities during outages.
- Outdoor Activities: Reliable power source for events, weddings, and outdoor gatherings.
- Construction Sites: Provides electricity for tools and facilities at remote construction locations.
- Remote Areas: Power solution for research stations, mining operations, and isolated locations.
Technical Specifications
| Specification | Unit | 2.8KW | 4.5KW | 5KW | 6KW | 8KW | 9KW |
|---|---|---|---|---|---|---|---|
| Frequency | Hz | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Rated Power | KW | 2.8 | 4.5 | 5 | 6 | 8 | 9 |
| Maximum Power | KW | 3 | 5.5 | 6 | 7 | 9 | 10 |
| Rated Voltage | V | 220 | 220 | 220 | 220 | 220 | 220 |
| Power Factor | Cos 0 | 1 | 1 | 1 | 1 | 1 | 1 |
| Engine Type | 178F | 186F | 188F | 192F | 1100FE | 1105FE | |
| Dimensions (L×W×H) | mm | 890×520×640 | 890×520×640 | 890×520×640 | 890×520×640 | 1100×650×735 | 1100×650×735 |
| Net Weight | kg | 130 | 140 | 150 | 160 | 190 | 195 |
| Noise Level | dB(A) | 70 | 70 | 70 | 70 | 70 | 70 |
| Engine Form | Single cylinder, air-cooled, four-stroke | ||||||
| Starting Mode | Electrical starting | ||||||
| Fuel Type | Diesel (summer -10°C, winter -35°C) | ||||||
| Lubricating Oil Type | 15W-40 | ||||||
| Lubricating Oil Capacity | L | 1.1 | 1.65 | 1.7 | 1.75 | 1.8 | 1.8 |
| Tank Capacity | L | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
| Price | USD | 495 | 505 | 520 | 600 | 790 | 950 |
Product Images
Frequently Asked Questions
Q: What is your MOQ of this item?
A: 1 Set
Q: What is the lead time?
A: 7 working days after receiving the 30% T/T deposit.
Q: Is it all right to make customer's own brand name?
A: We can be your OEM manufacturer with your brand authorization.
Q: Where is your Loading Port?
A: Shanghai or others.
Q: What are your payment terms?
A: 30% TT as deposit, 70% TT before shipment.
Q: What is your company's available production capacity?
A: 100 Sets per month.
Q: What's the warranty time of diesel generators?
A: 12 months or 1000 working hours, whichever comes first.
