3KW Portable Silent Diesel Generator 1500RPM 1800RPM 3600RPM
|
3KW Portable Silent Diesel Generator 1500RPM 1800RPM 3600RPM
| Place of Origin | Sichuan, China |
| Brand Name | JIWEI |
| Model Number | JW-CY3kw |
Product Details
Rated Voltage:
220V, 230V, 240V, 380V
Rated Current:
2.4A
Speed:
1500RPM, 1800RPM, 3600RPM
Frequency:
50/60hz, 60Hz, 50Hz
Starting System:
Auto Start, Recoil Start, Remote Start, 24V DC Electric Start, 12V DC Electric Start
Type:
Trailer Type, Silent Type, Container Type, Super Silent Type, Open Frame, Portable Type, Mobile Type
Warranty:
3months-1year
Product Name:
3KW Small Open Rack Diesel Generator
Color:
Customizable
Rated Power:
3KW
Highlight:
3KW Portable Silent Diesel Generator
,Portable Silent Diesel Generator 1500RPM
,1800RPM small diesel powered generator
Payment & Shipping Terms
Minimum Order Quantity
5
Price
negotiable
Delivery Time
15 work days
Payment Terms
T/T
Product Description
Power Supply 3KW Silent Small DG Set Diesel Generator With Automatic Transfer Switch
Emergency Power Supply 3KW Silent Diesel Generator Auto/Remote Start Open Frame
Overview
Peculiarities of the Generator
- Strong Power: High-performance diesel engine provides stable power output for continuous and reliable electricity generation.
- Good Fuel Economy: Optimized design promotes full fuel combustion, resulting in low fuel consumption and reduced operational costs.
- Quick Start: Electric start mode enables ignition within seconds for rapid power availability in emergencies.
- Simple Operation and Maintenance: User-friendly panel with long maintenance intervals and versatile, low-cost parts.
- High Reliability: Robust structure with protection devices including overload, short circuit, and low oil pressure protection.
Application Scenarios
- Emergency Power Supply: Critical locations like hospitals, shopping malls, and banks during grid failures.
- Construction Site: Powers tools, lighting equipment, lifts, and other machinery.
- Field Operation: Reliable power for mining, oil exploration, and field research in remote areas.
- Commercial Activities: Supports outdoor events, exhibitions, and temporary shops with power for lighting, audio, and air conditioning.
Technical Specifications
| Name | 2.0kW single phase | 2.5kW single phase | 2.8kW single phase | 5.0kW single phase | 5.0kW three-phase |
|---|---|---|---|---|---|
| Model | AWT2500(E) | AWT3500(E) | AWT3800(E) | AWT6500(E) | AWT6500S(E) |
| Engine Model | 170F/P(170FD/P) | 170F/P(170FD/P) | 170F/P(170FD/P) | 190F/P(190FD/P) | 190F/P(190FD/P) |
| Starting Mode | Hand pull recoil start/electric start | Hand pull recoil start/electric start | Hand pull recoil start/electric start | Hand pull recoil start/electric start | Hand pull recoil start/electric start |
| Phase Factor | Single-phase | Single-phase | Single-phase | Single-phase | Three-phase |
| Power Factor | 1.0 | 1.0 | 1.0 | 1.0 | 0.8 |
| Rated Voltage | 230V | 230V | 230V | 230V | 400V |
| Maximum Output | 2.2 kW | 2.7 kW | 3.0 kW | 5.5 kW | 5.5 kW |
| Rated Output | 2.0 kW | 2.5 kW | 2.8 kW | 5.0 kW | 5.0 kW |
| Rated Frequency | 50Hz | 50Hz | 50Hz | 50Hz | 50Hz |
| Pressure Regulation | AVR automatic | AVR automatic | AVR automatic | AVR automatic | AVR automatic |
| Noise | ≤75dB | ≤75dB | ≤75dB | ≤75dB | ≤75dB |
| Tank Volume | 15L | 15L | 15L | 25L | 25L |
| Oil Volume | 0.6 L | 0.6 L | 0.6 L | 1.1 L | 1.1 L |
| Overall Size | 590 * 435 * 430 | 590 * 435 * 430 | 590 * 435 * 430 | 680 * 510 * 545 | 680 * 510 * 545 |
| Carton Size | 610 * 455 * 460 | 610 * 455 * 460 | 610 * 455 * 460 | 700 * 530 * 575 | 700 * 530 * 575 |
| Net/Gross Weight | 38/40kg | 40/42kg | 43/45kg | 72/75kg | 72/75kg |
Frequently Asked Questions
Q: What is your MOQ of this item?
A: 5 Sets.
Q: What is the lead time?
A: 7 working days after receiving the 30% T/T deposit.
Q: Is it all right to make customer's own brand name?
A: We can be your OEM manufacturer with your authorization of brand.
Q: Where is your Loading Port?
A: Shanghai or others.
Q: What are your payment terms?
A: 30% TT as deposit, 70% TT before shipment.
Q: What is your company's available production capacity?
A: 10000 Sets per month.
