8kw Silent Diesel Generator Household Three Phase Silent Genset
|
8kw Silent Diesel Generator Household Three Phase Silent Genset
| Place of Origin | China |
| Brand Name | JIWEI |
| Certification | ce |
| Model Number | JW-YMT |
Product Details
Rated Voltage:
110V/220V/230V/380V/400V/440V,120 To 440V
Frequency:
50/60HZ
Speed:
3600rpm,3000/3600RPM,1500/1800
Rated Current:
5A-30A
Rated Power:
8kw
Output Type:
AC Single Phase,DC,AC 3 Phase,Other
Color:
Customizable
Engine Type:
Two-Cylinder Four-Stroke，Air-cooled Diesel Engine,ECU
Starting System:
Manual Start, Remote Start, Electric Start
Function:
Provide Electric Power
Fuel Tank Capacity:
10-25L，According To Customers' Requirement
Alternator Type:
Brush Alternator With AVR Or Brushless With AVR,Three Phase Alternator
Product:
8kw Silent Diesel Generator All-copper Household Construction Site 220V/380V Three-phase Generator
Highlight:
8kw silent diesel generator
,all-copper three-phase generator
,household construction site generator
Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Payment Terms
T/T
Product Description
8kw Silent Diesel Generator All-copper Household Construction Site 220V/380V Three-phase Generator
Overview
Silent diesel generators are specifically designed to minimize noise output, making them ideal for environments that require quiet operation. Below are the key features and applications of silent diesel generators.
Features
- Low Noise Design: Uses soundproof materials and specially designed silencers to significantly reduce operational noise.
- High Efficiency: Generally exhibits high fuel efficiency, providing stable power output over extended periods.
- Durability: Built with a robust diesel engine structure, suitable for long-running and heavy-load conditions.
- Portability: Many models are designed to be mobile, allowing for easy relocation and use in various settings.
- Environmental Protection: Complies with modern environmental standards, reducing emissions and ensuring eco-friendliness.
Applications
- Backup Power Supply: Acts as an emergency power source during outages, ensuring continuity for critical operations such as hospitals and data centers.
- Outdoor Activities: Supplies reliable power for events such as weddings, concerts, and other outdoor gatherings.
- Construction Sites: Provides electricity to construction sites lacking access to the electrical grid, powering tools and site facilities.
- Remote Areas: Delivers power for research stations, mining operations, and other activities in isolated locations.
Silent diesel generators are versatile and essential in maintaining power in sensitive and varied environments.
Specification
| MODEL | YMT6500 | YMT7500 |
|---|---|---|
| Rated Frequency(HZ) | 50 | 50 |
| Rated voltage(v) | 230 | 230 |
| Rated power(KW) | 5KW | 6KW |
| Number of phases | Single Phase | Single Phase |
| Size(mm) | 970*560*780 | 970*560*780 |
| Net weight(kg) | 148 | 149 |
| Fuel tank capacity (L) | 12.5 | 12.5 |
| Noise(decibels @7m) | 70 | 70 |
| Engine model | 186FAGE | 188FGE |
| Type | In-line,single cylinder,air-cooled,four-stroke | |
| Cylinder diameter(mm) | 86 | 88 |
| Piston stroke(mm) | 72 | 75 |
| Displacement(ml) | 418 | 456 |
| Fuel consumption rate g/kw*h | ≤275 | ≤270 |
| Rated speed(r/min) | 3000 | 3000 |
| Starting system | 12V starter motor | 12V starter motor |
| Insulation Class | H | H |
| Continuous working time(h) | 8 | 8 |
| Fuel grade | Diesel:0#(summer),-10#(winter) | |
| Oil grade | SAE 10W30(or CD grade or above) | |
| Optional configuration | ATS/remote control/various body designs | |
FAQ
Q: What is your MOQ of this item?
A: 1 Set.
Q: What is the lead time?
A: 7 working days after received the 30%T/T deposit.
Q: Is it all right to make customer's own brand name?
A: We can be your OEM manufacture with your authorization of brand.
Q: Where is your Loading Port?
A: Shanghai or others.
Q: What are your payment terms?
A: 30% TT as deposit, 70% TT before Shipment.
Q: What is your company's available production capacity?
A: 100 Sets per month.
Q: What's the warranty time of diesel generators?
A: 12 months or 1000 working hours, whichever comes first.
